GO-EMON THz wave
Generator consists of the ring cavity, non-collinear phase matched
frequency conversion and wavelength tuning structures. Due to the
ring cavity, GO-EMON achieves the narrow bandwidth of THz
(30-50GHz). The system requires the external pump source (Nd:YAG).
Max rep. rate is 500Hz and it can help to measure the data rapidly.
This system is designed and produced by PAX. Inc. based on the
patented technologies under contract to RIKEN, JAPAN.
|
|
|
|
|
|
|
|
Advantages
& Features
|
|
|
|
World smallest THz
wave radiation system ---
no cooling system required
|
|
Ring cavity design
for stable ----
narrower band width
|
|
Easy to use
--- only input the fundamental wavelength (1064nm) of Nd:YAG
laser
|
|
Si prism array
coupler --- Efficient THz wave output generated by non-collinear
phase matching condition
|
|
Tsurupica
Aspheric cylindrical window used for collimation of THz wave
---
No absorption at 2.2THz wave that Polyethylene material has
|
|
Synchronized to the
pump laser with up to 500 Hz rep. Rate (Motorized Option: GO-EMON-R)
|
|
Controllability of
the wavelength tuning speed (Motorized Option: GO-EMON-R)
|
|
|
|
Technical
Specifications
|
|
|
|
Tuning range
|
1-2.8 THz region （input:
20mJ/pulse @1064nm）
|
|
Bandwidth (THz wave)
|
30-50GHz (pulse width
of pump: 23nsec)
|
|
Peak output power
|
>100pJ/ pulse at
1.5 THz
|
|
Angle resolution
|
5 μrad (Motorized
Option: GO-EMON-R)
|
|
|
|
